26 Odpowiedź przez spamsool

  • Zarejestrowany: 2013-06-08
  • Posty: 490

Odp: Stick 5G/LTE na SDX55

Czy ten modem zadziała z OpenWRT/Gargoyle? Jesli dobrze rozumiem to on działa tak jak modemy USB Huawei HiLink czyli jest widoczny jako adapter sieciowy/router z własnym DHCP i interfejsem webowym do zmiany ustawień?

27 Odpowiedź przez MiG25 (edytowany przez MiG25 2025-11-29 22:25:30)

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Jak najbardziej. Do tego celu wyciągnąłem mojego wykastrowanego LBR20 ( zamiast zintegrowanego modemu ma wyprowadzony port USB3.0) .

Trzeba mieć zainstalowany pakiet kmod-usb-net-cdc-ether (więc ten sam co dla Hi-Linków) , no i wtedy system wykrywa go tak:

T:  Bus=02 Lev=01 Prnt=01 Port=00 Cnt=01 Dev#=  7 Spd=5000 MxCh= 0
D:  Ver= 3.20 Cls=ef(misc ) Sub=02 Prot=01 MxPS= 9 #Cfgs=  3
P:  Vendor=05c6 ProdID=9063 Rev= 4.14
S:  Manufacturer=Tri Cascade Inc.
S:  Product=VOS_5G
S:  SerialNumber=c17fc728
C:* #Ifs= 2 Cfg#= 1 Atr=a0 MxPwr=896mA
I:* If#= 0 Alt= 0 #EPs= 1 Cls=02(comm.) Sub=06 Prot=00 Driver=cdc_ether
E:  Ad=81(I) Atr=03(Int.) MxPS=  16 Ivl=32ms
I:  If#= 1 Alt= 0 #EPs= 0 Cls=0a(data ) Sub=00 Prot=00 Driver=cdc_ether
I:* If#= 1 Alt= 1 #EPs= 2 Cls=0a(data ) Sub=00 Prot=00 Driver=cdc_ether
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
C:  #Ifs= 2 Cfg#= 2 Atr=a0 MxPwr=896mA
A:  FirstIf#= 0 IfCount= 2 Cls=ef(misc ) Sub=04 Prot=01
I:  If#= 0 Alt= 0 #EPs= 1 Cls=ef(misc ) Sub=04 Prot=01 Driver=
E:  Ad=81(I) Atr=03(Int.) MxPS=   8 Ivl=32ms
I:  If#= 1 Alt= 0 #EPs= 2 Cls=0a(data ) Sub=00 Prot=00 Driver=
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
C:  #Ifs= 2 Cfg#= 3 Atr=a0 MxPwr=896mA
A:  FirstIf#= 0 IfCount= 2 Cls=02(comm.) Sub=0e Prot=00
I:  If#= 0 Alt= 0 #EPs= 1 Cls=02(comm.) Sub=0e Prot=00 Driver=
E:  Ad=81(I) Atr=03(Int.) MxPS=  64 Ivl=32ms
I:  If#= 1 Alt= 0 #EPs= 0 Cls=0a(data ) Sub=00 Prot=02 Driver=
I:  If#= 1 Alt= 1 #EPs= 2 Cls=0a(data ) Sub=00 Prot=02 Driver=
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms

A w dmesg odpowiedni log:

[  182.941741] usb 2-1: new SuperSpeed USB device number 2 using xhci-hcd
[  183.032907] cdc_ether 2-1:1.0 usb0: register 'cdc_ether' at usb-xhci-hcd.0.auto-1, CDC Ethernet Device, e6:3a:ad:d0:81:a9

Tyle ,że zamiast device eth1 ( jak to jest w opisie eko.one dla HiLink ) wybieramy (bądź wpisujemy) usb0....

Strona konfiguracyjna tego modemu 192.168.225.1 jak najbardziej też działa. Internet działa. Prędkość SuperSpeed ( więc USB3.0 i 5000Mbps)

Może bardziej należy użyć "hostless" i pakietu kmod-usb-net-rndis .... Zaraz zobaczę ,czy na nim będzie ok.

28 Odpowiedź przez Cezary

  • Skąd: Warszawa
  • Zarejestrowany: 2006-02-25
  • Posty: 115,877

Odp: Stick 5G/LTE na SDX55

Czekaj, ale masz tam trzy konfiguracje usb. Przełącz na inne i zobacz czym on będzie.

Masz niepotrzebny router, uszkodzony czy nie - chętnie przygarnę go.

Cezary's Strona

29 Odpowiedź przez MiG25

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Możesz przypomnieć jak się to robi .... ( kiedyś to robiłem , ale muszę szukać po forum tego...)

W każdym razie doinstalowanie kmod-usb-net-rndis nic nie zmieniło ( i jest ono i tak zależne od kmod-usb-net-cdc-ether)

30 Odpowiedź przez Cezary

  • Skąd: Warszawa
  • Zarejestrowany: 2006-02-25
  • Posty: 115,877

Odp: Stick 5G/LTE na SDX55

find /sys -name bConfigurationValue

Jeden ze znalezionych to będzie to od modemu. Wtedy w ten plik wpisujesz

echo 2 > bConfigurationValue

itd. Jak nie będzie chciało działać to najpierw 0 a później dopiero liczbę. Po wpisaniu poczekaj kilka sekund aż modem to przetrawi. Teraz masz pierwszą, sprawdź jakie sterowniki będą na 2 i 3.

Masz niepotrzebny router, uszkodzony czy nie - chętnie przygarnę go.

Cezary's Strona

31 Odpowiedź przez MiG25

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Ok , do drugiego configa sterwonik już wgrał się RNDIS:

root@OpenWrt:~# find /sys -name bConfigurationValue
/sys/devices/platform/soc/60f8800.usb/6000000.usb/xhci-hcd.1.auto/usb3/bConfigurationValue
/sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb1/bConfigurationValue
/sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/bConfigurationValue
/sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1/bConfigurationValue
root@OpenWrt:~# cat /sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1/bConfigurationValue
1
root@OpenWrt:~# echo 2 > /sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1/bConfigurationValue
root@OpenWrt:~# cat /sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1/bConfigurationValue
2
root@OpenWrt:~#

Co widać w dmesg i w usb/devices:

[ 1194.261614] cdc_ether 2-1:1.0 usb0: unregister 'cdc_ether' usb-xhci-hcd.0.auto-1, CDC Ethernet Device
[ 1194.511170] rndis_host 2-1:2.0 usb0: register 'rndis_host' at usb-xhci-hcd.0.auto-1, RNDIS device, 66:37:ed:59:b6:57


T:  Bus=02 Lev=01 Prnt=01 Port=00 Cnt=01 Dev#=  2 Spd=5000 MxCh= 0
D:  Ver= 3.20 Cls=ef(misc ) Sub=02 Prot=01 MxPS= 9 #Cfgs=  3
P:  Vendor=05c6 ProdID=9063 Rev= 4.14
S:  Manufacturer=Tri Cascade Inc.
S:  Product=VOS_5G
S:  SerialNumber=c17fc728
C:  #Ifs= 2 Cfg#= 1 Atr=a0 MxPwr=896mA
I:  If#= 0 Alt= 0 #EPs= 1 Cls=02(comm.) Sub=06 Prot=00 Driver=
E:  Ad=81(I) Atr=03(Int.) MxPS=  16 Ivl=32ms
I:  If#= 1 Alt= 0 #EPs= 0 Cls=0a(data ) Sub=00 Prot=00 Driver=
I:  If#= 1 Alt= 1 #EPs= 2 Cls=0a(data ) Sub=00 Prot=00 Driver=
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
C:* #Ifs= 2 Cfg#= 2 Atr=a0 MxPwr=896mA
A:  FirstIf#= 0 IfCount= 2 Cls=ef(misc ) Sub=04 Prot=01
I:* If#= 0 Alt= 0 #EPs= 1 Cls=ef(misc ) Sub=04 Prot=01 Driver=rndis_host
E:  Ad=81(I) Atr=03(Int.) MxPS=   8 Ivl=32ms
I:* If#= 1 Alt= 0 #EPs= 2 Cls=0a(data ) Sub=00 Prot=00 Driver=rndis_host
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
C:  #Ifs= 2 Cfg#= 3 Atr=a0 MxPwr=896mA
A:  FirstIf#= 0 IfCount= 2 Cls=02(comm.) Sub=0e Prot=00
I:  If#= 0 Alt= 0 #EPs= 1 Cls=02(comm.) Sub=0e Prot=00 Driver=
E:  Ad=81(I) Atr=03(Int.) MxPS=  64 Ivl=32ms
I:  If#= 1 Alt= 0 #EPs= 0 Cls=0a(data ) Sub=00 Prot=02 Driver=
I:  If#= 1 Alt= 1 #EPs= 2 Cls=0a(data ) Sub=00 Prot=02 Driver=
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms

Tylko w działaniu to raczej nic się nie zmieniło... Internet jest , strona konfiguracyjna modemu też jest...

32 Odpowiedź przez Cezary

  • Skąd: Warszawa
  • Zarejestrowany: 2006-02-25
  • Posty: 115,877

Odp: Stick 5G/LTE na SDX55

To jeszcze trójkę sprawdź.

Masz niepotrzebny router, uszkodzony czy nie - chętnie przygarnę go.

Cezary's Strona

33 Odpowiedź przez MiG25 (edytowany przez MiG25 2025-11-29 19:53:37)

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

No do trójki nie mam pakietu... I net się rozłącza
Może zgadniesz jaki to ? smile

T:  Bus=02 Lev=01 Prnt=01 Port=00 Cnt=01 Dev#=  2 Spd=5000 MxCh= 0
D:  Ver= 3.20 Cls=ef(misc ) Sub=02 Prot=01 MxPS= 9 #Cfgs=  3
P:  Vendor=05c6 ProdID=9063 Rev= 4.14
S:  Manufacturer=Tri Cascade Inc.
S:  Product=VOS_5G
S:  SerialNumber=c17fc728
C:  #Ifs= 2 Cfg#= 1 Atr=a0 MxPwr=896mA
I:  If#= 0 Alt= 0 #EPs= 1 Cls=02(comm.) Sub=06 Prot=00 Driver=
E:  Ad=81(I) Atr=03(Int.) MxPS=  16 Ivl=32ms
I:  If#= 1 Alt= 0 #EPs= 0 Cls=0a(data ) Sub=00 Prot=00 Driver=
I:  If#= 1 Alt= 1 #EPs= 2 Cls=0a(data ) Sub=00 Prot=00 Driver=
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
C:  #Ifs= 2 Cfg#= 2 Atr=a0 MxPwr=896mA
A:  FirstIf#= 0 IfCount= 2 Cls=ef(misc ) Sub=04 Prot=01
I:  If#= 0 Alt= 0 #EPs= 1 Cls=ef(misc ) Sub=04 Prot=01 Driver=
E:  Ad=81(I) Atr=03(Int.) MxPS=   8 Ivl=32ms
I:  If#= 1 Alt= 0 #EPs= 2 Cls=0a(data ) Sub=00 Prot=00 Driver=
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
C:* #Ifs= 2 Cfg#= 3 Atr=a0 MxPwr=896mA
A:  FirstIf#= 0 IfCount= 2 Cls=02(comm.) Sub=0e Prot=00
I:* If#= 0 Alt= 0 #EPs= 1 Cls=02(comm.) Sub=0e Prot=00 Driver=(none)
E:  Ad=81(I) Atr=03(Int.) MxPS=  64 Ivl=32ms
I:* If#= 1 Alt= 0 #EPs= 0 Cls=0a(data ) Sub=00 Prot=02 Driver=(none)
I:  If#= 1 Alt= 1 #EPs= 2 Cls=0a(data ) Sub=00 Prot=02 Driver=(none)
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms

EDIT: to cdc-mbim ....

34 Odpowiedź przez Cezary

  • Skąd: Warszawa
  • Zarejestrowany: 2006-02-25
  • Posty: 115,877

Odp: Stick 5G/LTE na SDX55

Tak, czyli albo z własnym gui albo mbim przez który możesz sterować modemem. Czyli mógłbyś modemmanagera na niego nasłać i zobaczysz czy przedstawia sie bandami. Choć to taki biały kruk że nie wiem czy mm go rozpozna czy będzie traktował jako generyczne urządzenie.

Masz niepotrzebny router, uszkodzony czy nie - chętnie przygarnę go.

Cezary's Strona

35 Odpowiedź przez MiG25

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Samo mmcli -L go znajduje.... Tylko na razie jeszcze nie udało mi się ,żeby w tym trybie był internet...

36 Odpowiedź przez MiG25

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Tak Modemmanager to widzi:

root@OpenWrt:~# mmcli -L
    /org/freedesktop/ModemManager1/Modem/0 [Tri Cascade Inc.] VOS_5G
root@OpenWrt:~# mmcli -m 0
  -----------------------------------
  General  |                    path: /org/freedesktop/ModemManager1/Modem/0
           |               device id: 66ede96783d2540bb8da04efc86edae24ca9ddf5
  -----------------------------------
  Hardware |            manufacturer: Tri Cascade Inc.
           |                   model: VOS_5G
           |       firmware revision: RXMG1.20.00.326.73_0R19
           |          carrier config: DT_Poland_Commercial
           | carrier config revision: 0A011F80
           |            h/w revision: SG500M2-X
           |               supported: gsm-umts, lte, 5gnr, tds
           |                          cdma-evdo, lte, 5gnr, tds
           |                          lte, 5gnr, tds
           |                          cdma-evdo, gsm-umts, lte, 5gnr, tds
           |                 current: gsm-umts, lte, 5gnr, tds
           |            equipment id: 016371000108313
  -----------------------------------
  System   |                  device: /sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1
           |                 physdev: /sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1
           |                 drivers: cdc_mbim
           |                  plugin: generic
           |            primary port: cdc-wdm0
           |                   ports: cdc-wdm0 (mbim), wwan0 (net)
  -----------------------------------
  Status   |                    lock: sim-pin2
           |          unlock retries: sim-pin2 (3)
           |                   state: disabled
           |             power state: on
  -----------------------------------
  Modes    |               supported: allowed: 2g; preferred: none
           |                          allowed: 3g; preferred: none
           |                          allowed: 2g, 3g; preferred: 3g
           |                          allowed: 2g, 3g; preferred: 2g
           |                          allowed: 2g, 4g; preferred: 4g
           |                          allowed: 2g, 4g; preferred: 2g
           |                          allowed: 3g, 4g; preferred: 4g
           |                          allowed: 3g, 4g; preferred: 3g
           |                          allowed: 2g, 3g, 4g; preferred: 4g
           |                          allowed: 2g, 3g, 4g; preferred: 3g
           |                          allowed: 2g, 3g, 4g; preferred: 2g
           |                          allowed: 2g, 5g; preferred: 5g
           |                          allowed: 2g, 5g; preferred: 2g
           |                          allowed: 3g, 5g; preferred: 5g
           |                          allowed: 3g, 5g; preferred: 3g
           |                          allowed: 2g, 3g, 5g; preferred: 5g
           |                          allowed: 2g, 3g, 5g; preferred: 3g
           |                          allowed: 2g, 3g, 5g; preferred: 2g
           |                          allowed: 2g, 4g, 5g; preferred: 5g
           |                          allowed: 2g, 4g, 5g; preferred: 4g
           |                          allowed: 2g, 4g, 5g; preferred: 2g
           |                          allowed: 3g, 4g, 5g; preferred: 5g
           |                          allowed: 3g, 4g, 5g; preferred: 4g
           |                          allowed: 3g, 4g, 5g; preferred: 3g
           |                          allowed: 2g, 3g, 4g, 5g; preferred: 5g
           |                          allowed: 2g, 3g, 4g, 5g; preferred: 4g
           |                          allowed: 2g, 3g, 4g, 5g; preferred: 3g
           |                          allowed: 2g, 3g, 4g, 5g; preferred: 2g
           |                 current: allowed: 3g, 4g, 5g; preferred: 5g
  -----------------------------------
  Bands    |               supported: utran-1, utran-3, utran-4, utran-6, utran-5, utran-8,
           |                          utran-9, utran-2, eutran-1, eutran-2, eutran-3, eutran-4, eutran-5,
           |                          eutran-7, eutran-8, eutran-12, eutran-13, eutran-14, eutran-17,
           |                          eutran-18, eutran-19, eutran-20, eutran-25, eutran-26, eutran-28,
           |                          eutran-29, eutran-30, eutran-32, eutran-34, eutran-38, eutran-39,
           |                          eutran-40, eutran-41, eutran-42, eutran-43, eutran-46, eutran-48,
           |                          eutran-66, eutran-71, cdma-bc0, cdma-bc1, cdma-bc10, utran-19,
           |                          ngran-1, ngran-2, ngran-3, ngran-5, ngran-7, ngran-8, ngran-12,
           |                          ngran-14, ngran-20, ngran-25, ngran-28, ngran-38, ngran-40, ngran-41,
           |                          ngran-48, ngran-66, ngran-71, ngran-77, ngran-78, ngran-79
           |                 current: utran-1, utran-3, utran-4, utran-6, utran-5, utran-8,
           |                          utran-9, utran-2, eutran-1, eutran-2, eutran-3, eutran-4, eutran-5,
           |                          eutran-7, eutran-8, eutran-12, eutran-17, eutran-20, eutran-28,
           |                          eutran-32, eutran-38, eutran-39, eutran-41, eutran-66, cdma-bc0,
           |                          cdma-bc1, cdma-bc10, utran-19, ngran-1, ngran-2, ngran-3, ngran-5,
           |                          ngran-7, ngran-8, ngran-12, ngran-20, ngran-25, ngran-28, ngran-38,
           |                          ngran-41, ngran-48, ngran-66, ngran-71, ngran-77, ngran-78, ngran-79
  -----------------------------------
  IP       |               supported: ipv4, ipv6, ipv4v6
  -----------------------------------
  3GPP     |                    imei: 016371000108313
           |           enabled locks: fixed-dialing
  -----------------------------------
  3GPP EPS |      initial bearer apn: internet
           |  initial bearer ip type: ipv4v6
  -----------------------------------
  SIM      |        primary sim path: /org/freedesktop/ModemManager1/SIM/0
           |          sim slot paths: slot 1: /org/freedesktop/ModemManager1/SIM/0 (active)
root@OpenWrt:~#

Ale w tym protokole OpenWRT nie łączy:

Sat Nov 29 20:34:10 2025 daemon.notice netifd: Interface 'wan' is now down
Sat Nov 29 20:34:10 2025 daemon.notice netifd: Interface 'wan' is setting up now
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601): mbim[13601] Reading capabilities
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   devicetype: 0001 - embedded
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   cellularclass: 0003
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   voiceclass: 0001 - no-voice
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   simclass: 0002
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   dataclass: 8037003C
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   smscaps: 0003
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   controlcaps: 000D
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   maxsessions: 000F
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   deviceid: 016371000108313
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   firmwareinfo: RXMG1.20.00.326.73_0R19
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   hardwareinfo: SG500M2-X
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601): mbim[13601] Checking pin
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601): required pin: 3 - pin2
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601): remaining attempts: 3
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601): mbim[13601] Checking subscriber
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   readystate: 0001 - initialized
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   simiccid: 8948022715110xxxxxxx
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   subscriberid: 260022072093937
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601): mbim[13601] Register with network
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   nwerror: 0000 - unknown
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   registerstate: 0003 - home
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   registermode: 0001 - automatic
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   availabledataclasses: 80000020 - (null)
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   currentcellularclass: 0001 - gsm
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   provider_id: 26002
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   provider_name: T-Mobile.pl
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   roamingtext: (null)
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601): mbim[13601] Registered in home mode
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601): mbim[13601] Attach to network
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   nwerror: 0000 - unknown
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   packetservicestate: 0002 - attached
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   uplinkspeed: 0
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601):   downlinkspeed: 0
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601): mbim[13601] Connect to network
Sat Nov 29 20:34:10 2025 daemon.notice netifd: wan (13601): mbim[13601] Failed to connect bearer
Sat Nov 29 20:34:11 2025 user.notice root: mbim bringup failed, retry in 15s
Sat Nov 29 20:34:11 2025 daemon.warn odhcpd[1760]: No default route present, setting ra_lifetime to 0!
Sat Nov 29 20:34:12 2025 daemon.info dnsmasq[1]: read /etc/hosts - 12 names
Sat Nov 29 20:34:12 2025 daemon.info dnsmasq[1]: read /tmp/hosts/dhcp.cfg01411c - 4 names
Sat Nov 29 20:34:12 2025 daemon.info dnsmasq[1]: read /tmp/hosts/odhcpd - 2 names
Sat Nov 29 20:34:12 2025 daemon.info dnsmasq-dhcp[1]: read /etc/ethers - 0 addresses

37 Odpowiedź przez Cezary

  • Skąd: Warszawa
  • Zarejestrowany: 2006-02-25
  • Posty: 115,877

Odp: Stick 5G/LTE na SDX55

Zrób

ifdown wan
umbim -d /dev/cdc-wdm0 radio on
ifup wan
Masz niepotrzebny router, uszkodzony czy nie - chętnie przygarnę go.

Cezary's Strona

38 Odpowiedź przez MiG25

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Nic nie poprawia:

root@OpenWrt:~# ifdown wan
root@OpenWrt:~# umbim -d /dev/cdc-wdm0 radio on
  hwradiostate: on
  swradiostate: on
root@OpenWrt:~# ifup wan
root@OpenWrt:~#

czasami też ta komenda trwala tak długo ,że był timeout

wan raczej dobrze skonfigurowany

config interface 'wan'
        option proto 'mbim'
        option device '/dev/cdc-wdm0'
        option apn 'internet'
        option auth 'none'
        option pdptype 'ipv4'
        option auto '0'

39 Odpowiedź przez Cezary

  • Skąd: Warszawa
  • Zarejestrowany: 2006-02-25
  • Posty: 115,877

Odp: Stick 5G/LTE na SDX55

Nie, korzystasz z umbim a nie modemmanagera.

config interface 'wan'
    option device   'sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1'
    option proto    'modemmanager'
    option apn      'internet'

Jeżeli faktycznie takie masz device.

Masz niepotrzebny router, uszkodzony czy nie - chętnie przygarnę go.

Cezary's Strona

40 Odpowiedź przez MiG25

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

No jest inaczej , ale czy gorzej...
w logach totalnie nic nie widać teraz. ifup wan nic tam nie wpisuje.
Luci pokazuje ,że urzadzenie sieciowe nie jest dostępne , choć go jednoczesnie pokazuje...
https://i.ibb.co/6RV9htNr/Zrzut-ekranu-2025-11-29-214802.png

41 Odpowiedź przez Cezary

  • Skąd: Warszawa
  • Zarejestrowany: 2006-02-25
  • Posty: 115,877

Odp: Stick 5G/LTE na SDX55

Egzotyka panie, egzotyka...

Masz niepotrzebny router, uszkodzony czy nie - chętnie przygarnę go.

Cezary's Strona

42 Odpowiedź przez MiG25

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Po wyłączeniu i włączeniu coś się jednak zaczęło dziać w logach ( ale nic co by było sukcesem)

Sat Nov 29 21:47:05 2025 kern.info kernel: [   57.741312] cdc_ether 2-1:1.0 usb0: unregister 'cdc_ether' usb-xhci-hcd.0.auto-1, CDC Ethernet Device
Sat Nov 29 21:47:05 2025 daemon.info ModemManager[5378]: hotplug: remove network interface usb0: event processed
Sat Nov 29 21:47:05 2025 daemon.notice [2499]: <msg> [base-manager] port usb0 released by device '/sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1'
Sat Nov 29 21:47:05 2025 daemon.notice [2499]: <msg> [base-manager] couldn't check support for device '/sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1': Operation was cancelled
Sat Nov 29 21:47:05 2025 kern.info kernel: [   57.962362] cdc_mbim 2-1:3.0: setting rx_max = 16384
Sat Nov 29 21:47:05 2025 kern.info kernel: [   57.963509] cdc_mbim 2-1:3.0: cdc-wdm0: USB WDM device
Sat Nov 29 21:47:05 2025 kern.info kernel: [   57.967764] cdc_mbim 2-1:3.0 wwan0: register 'cdc_mbim' at usb-xhci-hcd.0.auto-1, CDC MBIM, 36:ac:3b:52:23:28
Sat Nov 29 21:47:05 2025 daemon.info ModemManager[5412]: hotplug: add network interface wwan0: event processed
Sat Nov 29 21:47:05 2025 daemon.info ModemManager[5412]: hotplug: add cdc interface cdc-wdm0: custom event processed
Sat Nov 29 21:47:06 2025 daemon.warn odhcpd[2029]: No default route present, setting ra_lifetime to 0!
Sat Nov 29 21:47:08 2025 daemon.notice [2499]: <msg> [cdc-wdm0/mbim] MBIM device is not QMI capable
Sat Nov 29 21:47:09 2025 daemon.notice [2499]: <msg> [device /sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1] creating modem with plugin 'generic' and '2' ports
Sat Nov 29 21:47:09 2025 daemon.info [2499]: <inf> [modem0] net/wwan0: net (data)
Sat Nov 29 21:47:09 2025 daemon.info [2499]: <inf> [modem0] usbmisc/cdc-wdm0: mbim
Sat Nov 29 21:47:09 2025 daemon.notice [2499]: <msg> [base-manager] modem for device '/sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1' successfully created
Sat Nov 29 21:47:10 2025 daemon.notice [2499]: <msg> [modem0/cdc-wdm0/mbim] MBIM device is QMI capable
Sat Nov 29 21:47:12 2025 daemon.warn [2499]: <wrn> [modem0] unhandled QMI radio interface '9'
Sat Nov 29 21:47:12 2025 daemon.warn [2499]: <wrn> [modem0] unhandled QMI radio interface '9'
Sat Nov 29 21:47:12 2025 daemon.info [2499]: <inf> [modem0] SIM hot swap setup succeeded
Sat Nov 29 21:47:12 2025 daemon.info [2499]: <inf> [modem0] SIM is ready, and no need for the after SIM unlock step...
Sat Nov 29 21:47:12 2025 daemon.info [2499]: <inf> [modem0/sim0] loaded IMSI: ###
Sat Nov 29 21:47:12 2025 daemon.info [2499]: <inf> [modem0/sim0] loaded operator identifier: 26002
Sat Nov 29 21:47:12 2025 daemon.info [2499]: <inf> [modem0/sim0] loaded operator name: T-Mobile.pl
Sat Nov 29 21:47:12 2025 daemon.info [2499]: <inf> [modem0/sim0] loaded list of preferred networks:
Sat Nov 29 21:47:12 2025 daemon.warn [2499]: <wrn> [modem0] couldn't load supported assistance data types: LOC service: general failure
Sat Nov 29 21:47:13 2025 daemon.notice [2499]: <msg> [modem0] state changed (unknown -> disabled)
Sat Nov 29 21:47:13 2025 daemon.info ModemManager[2449]: hotplug: interface 'wan' set '/sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1' state available
Sat Nov 29 21:47:13 2025 daemon.notice netifd: Interface 'wan' is setting up now
Sat Nov 29 21:47:13 2025 daemon.notice netifd: wan (5494): modem available at /org/freedesktop/ModemManager1/Modem/0
Sat Nov 29 21:47:13 2025 daemon.info [2499]: <inf> [modem0] processing user request to enable modem...
Sat Nov 29 21:47:13 2025 daemon.notice [2499]: <msg> [modem0] state changed (disabled -> enabling)
Sat Nov 29 21:47:13 2025 daemon.notice [2499]: <msg> [modem0] power state updated: on
Sat Nov 29 21:47:13 2025 daemon.info [2499]: <inf> [modem0] checking if SIM was swapped...
Sat Nov 29 21:47:13 2025 daemon.info [2499]: <inf> [modem0] SIM identifier has not changed: ###
Sat Nov 29 21:47:13 2025 daemon.info [2499]: <inf> [modem0] SIM imsi has not changed: ###
Sat Nov 29 21:47:13 2025 daemon.notice [2499]: <msg> [modem0] 3GPP packet service state changed (unknown -> attached)
Sat Nov 29 21:47:13 2025 daemon.info [2499]: <inf> [modem0] enabled modem
Sat Nov 29 21:47:13 2025 daemon.notice [2499]: <msg> [modem0] state changed (enabling -> enabled)
Sat Nov 29 21:47:13 2025 daemon.notice [2499]: <msg> [modem0] 3GPP registration state changed (unknown -> registering)
Sat Nov 29 21:47:13 2025 daemon.notice netifd: wan (5494): successfully enabled the modem
Sat Nov 29 21:47:13 2025 daemon.info [2499]: <inf> [modem0] access technology changed (unknown -> lte, 5gnr)
Sat Nov 29 21:47:13 2025 daemon.notice netifd: wan (5494): setting allowed mode to 'any'
Sat Nov 29 21:47:13 2025 daemon.notice [2499]: <msg> [modem0] 3GPP registration state changed (registering -> home)
Sat Nov 29 21:47:13 2025 daemon.info [2499]: <inf> [modem0] consolidated registration state: cs 'idle', ps 'idle', eps 'home', 5gs 'home' --> 'home'
Sat Nov 29 21:47:13 2025 daemon.notice [2499]: <msg> [modem0] state changed (enabled -> registered)
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0] processing user request to set current modes to 'any' (preferred 'none')...
Sat Nov 29 21:47:14 2025 daemon.warn [2499]: <wrn> [modem0] unhandled QMI radio interface '9'
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0] current modes set to 'any' (preferred 'none')
Sat Nov 29 21:47:14 2025 daemon.notice netifd: wan (5494): successfully set current modes in the modem
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0] processing user request to register modem...
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0] already registered automatically in network '26002', automatic registration not launched...
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0] modem registered
Sat Nov 29 21:47:14 2025 daemon.notice netifd: wan (5494): successfully registered the modem
Sat Nov 29 21:47:14 2025 daemon.notice netifd: wan (5494): starting connection with apn 'internet'...
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0] processing user request to connect modem...
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0]   apn: internet
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0]   ip type: ipv4v6
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0]   allowed auth: unknown
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0]   allow roaming: yes
Sat Nov 29 21:47:14 2025 daemon.notice [2499]: <msg> [modem0] simple connect started...
Sat Nov 29 21:47:14 2025 daemon.notice [2499]: <msg> [modem0] simple connect state (6/10): register
Sat Nov 29 21:47:14 2025 daemon.info [2499]: <inf> [modem0] already registered automatically in network '26002', automatic registration not launched...
Sat Nov 29 21:47:14 2025 daemon.notice [2499]: <msg> [modem0] simple connect state (7/10): wait to get packet service state attached
Sat Nov 29 21:47:14 2025 daemon.notice [2499]: <msg> [modem0] simple connect state (8/10): bearer
Sat Nov 29 21:47:14 2025 daemon.notice [2499]: <msg> [modem0] simple connect state (9/10): connect
Sat Nov 29 21:47:14 2025 daemon.notice [2499]: <msg> [modem0] state changed (registered -> connecting)
Sat Nov 29 21:47:14 2025 daemon.warn [2499]: <wrn> [modem0/bearer1] connection attempt #1 failed: Failure
Sat Nov 29 21:47:14 2025 daemon.notice [2499]: <msg> [modem0] state changed (connecting -> registered)
Sat Nov 29 21:47:14 2025 daemon.notice [2499]: <msg> [modem0/bearer1] connection #1 finished: duration 0s
Sat Nov 29 21:47:14 2025 daemon.warn [2499]: <wrn> [modem0] couldn't connect bearer: Failure
Sat Nov 29 21:47:14 2025 daemon.notice netifd: wan (5494): error: couldn't connect the modem: 'GDBus.Error:org.freedesktop.libmbim.Error.Status.Failure: Failure'
Sat Nov 29 21:47:14 2025 daemon.notice netifd: wan (5547): stopping network
Sat Nov 29 21:47:15 2025 daemon.info [2499]: <inf> [modem0] processing user request to disconnect modem: all bearers
Sat Nov 29 21:47:15 2025 daemon.info [2499]: <inf> [modem0] all requested bearers disconnected
Sat Nov 29 21:47:15 2025 daemon.notice netifd: wan (5547): successfully disconnected all bearers in the modem
Sat Nov 29 21:47:15 2025 daemon.info [2499]: <inf> [modem0] processing user request to disable modem...
Sat Nov 29 21:47:15 2025 daemon.notice [2499]: <msg> [modem0] state changed (registered -> disabling)
Sat Nov 29 21:47:15 2025 daemon.notice [2499]: <msg> [modem0] 3GPP packet service state changed (attached -> unknown)
Sat Nov 29 21:47:15 2025 daemon.notice [2499]: <msg> [modem0] 3GPP registration state changed (home -> unknown)
Sat Nov 29 21:47:15 2025 daemon.info [2499]: <inf> [modem0] consolidated registration state: cs 'idle', ps 'idle', eps 'home', 5gs 'home' --> 'unknown'
Sat Nov 29 21:47:15 2025 daemon.notice [2499]: <msg> [modem0] 3GPP packet service state changed (unknown -> detached)
Sat Nov 29 21:47:15 2025 daemon.info [2499]: <inf> [modem0] access technology changed (lte, 5gnr -> unknown)
Sat Nov 29 21:47:15 2025 daemon.info [2499]: <inf> [modem0] disabled modem
Sat Nov 29 21:47:15 2025 daemon.notice [2499]: <msg> [modem0] state changed (disabling -> disabled)
Sat Nov 29 21:47:15 2025 daemon.notice netifd: wan (5547): successfully disabled the modem
Sat Nov 29 21:47:15 2025 daemon.notice netifd: Interface 'wan' is now down
Sat Nov 29 21:47:16 2025 daemon.warn odhcpd[2029]: No default route present, setting ra_lifetime to 0!
Sat Nov 29 21:47:16 2025 daemon.err collectd[2617]: rrdtool plugin: rrd_update_r failed: /tmp/rrd/OpenWrt/cpu-2/percent-interrupt.rrd: Not enough arguments
Sat Nov 29 21:47:16 2025 daemon.err collectd[2617]: rrdtool plugin: rrd_update_r failed: /tmp/rrd/OpenWrt/cpu-2/percent-idle.rrd: Not enough arguments
Sat Nov 29 21:47:16 2025 daemon.err collectd[2617]: rrdtool plugin: rrd_update_r failed: /tmp/rrd/OpenWrt/cpu-3/percent-system.rrd: Not enough arguments
Sat Nov 29 21:47:16 2025 daemon.err collectd[2617]: rrdtool plugin: rrd_update_r failed: /tmp/rrd/OpenWrt/memory/memory-free.rrd: Not enough arguments
Sat Nov 29 21:47:17 2025 daemon.info dnsmasq[1]: read /etc/hosts - 12 names
Sat Nov 29 21:47:17 2025 daemon.info dnsmasq[1]: read /tmp/hosts/dhcp.cfg01411c - 4 names
Sat Nov 29 21:47:17 2025 daemon.info dnsmasq[1]: read /tmp/hosts/odhcpd - 2 names
Sat Nov 29 21:47:17 2025 daemon.info dnsmasq-dhcp[1]: read /etc/ethers - 0 addresses
Sat Nov 29 21:48:09 2025 daemon.err uhttpd[2225]: [info] luci: accepted login on /admin/network/network for root from 192.168.11.188
Sat Nov 29 21:48:26 2025 daemon.notice netifd: Interface 'wan' is setting up now
Sat Nov 29 21:48:26 2025 daemon.notice netifd: wan (5962): modem available at /org/freedesktop/ModemManager1/Modem/0
Sat Nov 29 21:48:26 2025 daemon.info [2499]: <inf> [modem0] processing user request to disconnect modem: all bearers
Sat Nov 29 21:48:26 2025 daemon.info [2499]: <inf> [modem0] all requested bearers disconnected
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] processing user request to delete bearer '/org/freedesktop/ModemManager1/Bearer/1'...
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] deleted bearer '/org/freedesktop/ModemManager1/Bearer/1'
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] processing user request to enable modem...
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] state changed (disabled -> enabling)
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] power state updated: on
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] checking if SIM was swapped...
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] SIM identifier has not changed: ###
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] SIM imsi has not changed: ###
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] enabled modem
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] state changed (enabling -> enabled)
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] 3GPP registration state changed (unknown -> registering)
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] access technology changed (unknown -> lte, 5gnr)
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] 3GPP registration state changed (registering -> home)
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] consolidated registration state: cs 'idle', ps 'idle', eps 'home', 5gs 'home' --> 'home'
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] state changed (enabled -> registered)
Sat Nov 29 21:48:27 2025 daemon.notice netifd: wan (5962): successfully enabled the modem
Sat Nov 29 21:48:27 2025 daemon.notice netifd: wan (5962): setting allowed mode to 'any'
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] 3GPP packet service state changed (detached -> attached)
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] processing user request to set current modes to 'any' (preferred 'none')...
Sat Nov 29 21:48:27 2025 daemon.warn [2499]: <wrn> [modem0] unhandled QMI radio interface '9'
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] current modes set to 'any' (preferred 'none')
Sat Nov 29 21:48:27 2025 daemon.notice netifd: wan (5962): successfully set current modes in the modem
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] processing user request to register modem...
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] already registered automatically in network '26002', automatic registration not launched...
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] modem registered
Sat Nov 29 21:48:27 2025 daemon.notice netifd: wan (5962): successfully registered the modem
Sat Nov 29 21:48:27 2025 daemon.notice netifd: wan (5962): starting connection with apn 'internet'...
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] processing user request to connect modem...
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0]   apn: internet
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0]   ip type: ipv4v6
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0]   allowed auth: unknown
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0]   allow roaming: yes
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] simple connect started...
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] simple connect state (6/10): register
Sat Nov 29 21:48:27 2025 daemon.info [2499]: <inf> [modem0] already registered automatically in network '26002', automatic registration not launched...
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] simple connect state (7/10): wait to get packet service state attached
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] simple connect state (8/10): bearer
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] simple connect state (9/10): connect
Sat Nov 29 21:48:27 2025 daemon.notice [2499]: <msg> [modem0] state changed (registered -> connecting)
Sat Nov 29 21:48:28 2025 daemon.warn [2499]: <wrn> [modem0/bearer3] connection attempt #1 failed: Failure
Sat Nov 29 21:48:28 2025 daemon.notice [2499]: <msg> [modem0] state changed (connecting -> registered)
Sat Nov 29 21:48:28 2025 daemon.notice [2499]: <msg> [modem0/bearer3] connection #1 finished: duration 0s
Sat Nov 29 21:48:28 2025 daemon.warn [2499]: <wrn> [modem0] couldn't connect bearer: Failure
Sat Nov 29 21:48:28 2025 daemon.notice netifd: wan (5962): error: couldn't connect the modem: 'GDBus.Error:org.freedesktop.libmbim.Error.Status.Failure: Failure'
Sat Nov 29 21:48:28 2025 daemon.notice netifd: wan (6028): stopping network
Sat Nov 29 21:48:28 2025 daemon.info [2499]: <inf> [modem0] processing user request to disconnect modem: all bearers
Sat Nov 29 21:48:28 2025 daemon.info [2499]: <inf> [modem0] all requested bearers disconnected
Sat Nov 29 21:48:28 2025 daemon.notice netifd: wan (6028): successfully disconnected all bearers in the modem
Sat Nov 29 21:48:28 2025 daemon.info [2499]: <inf> [modem0] processing user request to disable modem...
Sat Nov 29 21:48:28 2025 daemon.notice [2499]: <msg> [modem0] state changed (registered -> disabling)
Sat Nov 29 21:48:28 2025 daemon.notice [2499]: <msg> [modem0] 3GPP packet service state changed (attached -> unknown)
Sat Nov 29 21:48:28 2025 daemon.notice [2499]: <msg> [modem0] 3GPP registration state changed (home -> unknown)
Sat Nov 29 21:48:28 2025 daemon.info [2499]: <inf> [modem0] consolidated registration state: cs 'idle', ps 'idle', eps 'home', 5gs 'home' --> 'unknown'
Sat Nov 29 21:48:28 2025 daemon.notice [2499]: <msg> [modem0] 3GPP packet service state changed (unknown -> detached)
Sat Nov 29 21:48:28 2025 daemon.info [2499]: <inf> [modem0] access technology changed (lte, 5gnr -> unknown)
Sat Nov 29 21:48:28 2025 daemon.info [2499]: <inf> [modem0] disabled modem
Sat Nov 29 21:48:28 2025 daemon.notice [2499]: <msg> [modem0] state changed (disabling -> disabled)
Sat Nov 29 21:48:28 2025 daemon.notice netifd: wan (6028): successfully disabled the modem
Sat Nov 29 21:48:28 2025 daemon.notice netifd: Interface 'wan' is now down
Sat Nov 29 21:48:29 2025 daemon.warn odhcpd[2029]: No default route present, setting ra_lifetime to 0!
Sat Nov 29 21:48:30 2025 daemon.info dnsmasq[1]: read /etc/hosts - 12 names
Sat Nov 29 21:48:30 2025 daemon.info dnsmasq[1]: read /tmp/hosts/dhcp.cfg01411c - 4 names
Sat Nov 29 21:48:30 2025 daemon.info dnsmasq[1]: read /tmp/hosts/odhcpd - 2 names
Sat Nov 29 21:48:30 2025 daemon.info dnsmasq-dhcp[1]: read /etc/ethers - 0 addresses
Sat Nov 29 21:49:10 2025 daemon.notice netifd: Interface 'wan' is setting up now
Sat Nov 29 21:49:10 2025 daemon.notice netifd: wan (6383): modem available at /org/freedesktop/ModemManager1/Modem/0
Sat Nov 29 21:49:10 2025 daemon.info [2499]: <inf> [modem0] processing user request to disconnect modem: all bearers
Sat Nov 29 21:49:10 2025 daemon.info [2499]: <inf> [modem0] all requested bearers disconnected
Sat Nov 29 21:49:11 2025 daemon.info [2499]: <inf> [modem0] processing user request to delete bearer '/org/freedesktop/ModemManager1/Bearer/3'...
Sat Nov 29 21:49:11 2025 daemon.info [2499]: <inf> [modem0] deleted bearer '/org/freedesktop/ModemManager1/Bearer/3'
Sat Nov 29 21:49:11 2025 daemon.info [2499]: <inf> [modem0] processing user request to enable modem...
Sat Nov 29 21:49:11 2025 daemon.notice [2499]: <msg> [modem0] state changed (disabled -> enabling)
Sat Nov 29 21:49:11 2025 daemon.notice [2499]: <msg> [modem0] power state updated: on
Sat Nov 29 21:49:11 2025 daemon.info [2499]: <inf> [modem0] checking if SIM was swapped...
Sat Nov 29 21:49:11 2025 daemon.warn [2499]: <wrn> [/dev/cdc-wdm0] MBIM error: MBIM protocol error: NotOpened
Sat Nov 29 21:49:21 2025 daemon.warn [2499]: <wrn> [modem0] could not load SIM identifier: QMI operation failed: Transaction timed out (3 retries left)
Sat Nov 29 21:49:22 2025 daemon.warn [2499]: <wrn> [/dev/cdc-wdm0] MBIM error: MBIM protocol error: NotOpened
Sat Nov 29 21:49:32 2025 daemon.warn [2499]: <wrn> [modem0] could not load SIM identifier: QMI operation failed: Transaction timed out (2 retries left)
Sat Nov 29 21:49:33 2025 daemon.warn [2499]: <wrn> [/dev/cdc-wdm0] MBIM error: MBIM protocol error: NotOpened
Sat Nov 29 21:49:43 2025 daemon.warn [2499]: <wrn> [modem0] could not load SIM identifier: QMI operation failed: Transaction timed out (1 retries left)
Sat Nov 29 21:49:44 2025 daemon.warn [2499]: <wrn> [/dev/cdc-wdm0] MBIM error: MBIM protocol error: NotOpened
Sat Nov 29 21:49:54 2025 daemon.warn [2499]: <wrn> [modem0] could not load SIM identifier: QMI operation failed: Transaction timed out
Sat Nov 29 21:49:54 2025 daemon.notice [2499]: <msg> [modem0] SIM identifier has changed: '###' -> '###'
Sat Nov 29 21:49:54 2025 daemon.info [2499]: <inf> [modem0] Processing SIM event
Sat Nov 29 21:49:54 2025 daemon.info [2499]: <inf> [modem0] enabled modem
Sat Nov 29 21:49:54 2025 daemon.notice [2499]: <msg> [modem0] state changed (enabling -> enabled)
Sat Nov 29 21:49:54 2025 daemon.notice [2499]: <msg> [modem0] state changed (enabled -> disabling)
Sat Nov 29 21:49:54 2025 daemon.notice netifd: wan (6383): successfully enabled the modem
Sat Nov 29 21:49:54 2025 daemon.warn [2499]: <wrn> [modem0] initial 3GPP registration check failed: MBIM protocol error: NotOpened
Sat Nov 29 21:49:54 2025 daemon.notice netifd: wan (6383): setting allowed mode to 'any'
Sat Nov 29 21:49:54 2025 daemon.notice [2499]: <msg> [modem0] 3GPP packet service state changed (detached -> unknown)
Sat Nov 29 21:49:54 2025 daemon.notice netifd: wan (6383): error: couldn't find modem
Sat Nov 29 21:49:54 2025 daemon.notice netifd: wan (6474): stopping network
Sat Nov 29 21:49:54 2025 daemon.notice netifd: wan (6474): error: couldn't find modem
Sat Nov 29 21:49:54 2025 daemon.notice netifd: wan (6474): couldn't load bearer path: disconnecting anyway
Sat Nov 29 21:49:54 2025 daemon.notice netifd: Interface 'wan' is now down
Sat Nov 29 21:49:55 2025 daemon.warn odhcpd[2029]: No default route present, setting ra_lifetime to 0!
Sat Nov 29 21:49:56 2025 daemon.notice [2499]: <msg> [device /sys/devices/platform/soc/8af8800.usb/8a00000.usb/xhci-hcd.0.auto/usb2/2-1] creating modem with plugin 'generic' and '2' ports
Sat Nov 29 21:49:56 2025 daemon.info [2499]: <inf> [modem1] net/wwan0: net (data)
Sat Nov 29 21:49:56 2025 daemon.info [2499]: <inf> [modem1] usbmisc/cdc-wdm0: mbim
Sat Nov 29 21:49:56 2025 daemon.warn [2499]: <wrn> [modem1] couldn't start initialization: MBIM protocol error: NotOpened
Sat Nov 29 21:49:56 2025 daemon.err [2499]: <err> [modem1] fatal error initializing: Fatal error: modem is unusable
Sat Nov 29 21:49:56 2025 daemon.info dnsmasq[1]: read /etc/hosts - 12 names
Sat Nov 29 21:49:56 2025 daemon.info dnsmasq[1]: read /tmp/hosts/dhcp.cfg01411c - 4 names
Sat Nov 29 21:49:56 2025 daemon.info dnsmasq[1]: read /tmp/hosts/odhcpd - 2 names
Sat Nov 29 21:49:56 2025 daemon.info dnsmasq-dhcp[1]: read /etc/ethers - 0 addresses
Sat Nov 29 21:49:58 2025 daemon.warn [2499]: <wrn> [/dev/cdc-wdm0] MBIM error: Transaction timed out
Sat Nov 29 21:49:58 2025 daemon.warn [2499]: <wrn> [/dev/cdc-wdm0] MBIM error: Transaction timed out
Sat Nov 29 21:49:58 2025 daemon.warn [2499]: <wrn> [/dev/cdc-wdm0] MBIM error: Transaction timed out
Sat Nov 29 21:49:58 2025 daemon.warn [2499]: <wrn> [/dev/cdc-wdm0] MBIM error: Transaction timed out
Sat Nov 29 21:49:58 2025 daemon.warn [2499]: <wrn> [/dev/cdc-wdm0] MBIM error: Transaction timed out

43 Odpowiedź przez MiG25

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Ze strony https://www.tricascadeinc.com/internaldownloadcenter ściągnąłem Switch_Tool , który przełącza modem w tryb rndis i dodatkowo daje porty m.n. adb i port do komend AT...
Aby uruchomić Switch_Tool potrzebna jest jeszcze instalacja Visual-C-Runtimes w wersji na x86 ( mimo ,że mamy zapewne sprzęt x64) także plik VC_redist.x86.exe ....

No i po przełączeniu na OpenWRT trzeba najpierw zainstalować adb , oraz zainicjować sterownik do adb komendą "adb devices" , wtedy będziemy mieli takie coś"

T:  Bus=02 Lev=01 Prnt=01 Port=00 Cnt=01 Dev#=  2 Spd=5000 MxCh= 0
D:  Ver= 3.20 Cls=00(>ifc ) Sub=00 Prot=00 MxPS= 9 #Cfgs=  1
P:  Vendor=04b7 ProdID=9058 Rev= 4.14
S:  Manufacturer=Tri Cascade Inc.
S:  Product=VOS_5G
S:  SerialNumber=c17fc728
C:* #Ifs= 5 Cfg#= 1 Atr=a0 MxPwr=896mA
A:  FirstIf#= 0 IfCount= 2 Cls=ef(misc ) Sub=04 Prot=01
I:* If#= 0 Alt= 0 #EPs= 1 Cls=ef(misc ) Sub=04 Prot=01 Driver=rndis_host
E:  Ad=81(I) Atr=03(Int.) MxPS=   8 Ivl=32ms
I:* If#= 1 Alt= 0 #EPs= 2 Cls=0a(data ) Sub=00 Prot=00 Driver=rndis_host
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
I:* If#= 2 Alt= 0 #EPs= 2 Cls=ff(vend.) Sub=ff Prot=30 Driver=(none)
E:  Ad=82(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=01(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
I:* If#= 3 Alt= 0 #EPs= 2 Cls=ff(vend.) Sub=42 Prot=01 Driver=usbfs
E:  Ad=02(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=83(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
I:* If#= 4 Alt= 0 #EPs= 3 Cls=ff(vend.) Sub=00 Prot=00 Driver=(none)
E:  Ad=85(I) Atr=03(Int.) MxPS=  10 Ivl=32ms
E:  Ad=84(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=03(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms

Po czym możemy ręcznie dodać option :

echo "04b7 9058" > /sys/bus/usb-serial/drivers/option1/new_id

Bez wcześniejszego wykrycia adb , porty szeregowe przejełby również ten od adb , i modem w momencie by się zawiesił...

No i teraz już na porcie ttyUSB1 są komendy AT:

root@OpenWrt:~# picocom /dev/ttyUSB1
picocom v3.1

port is        : /dev/ttyUSB1
flowcontrol    : none
baudrate is    : 9600
parity is      : none
databits are   : 8
stopbits are   : 1
escape is      : C-a
local echo is  : no
noinit is      : no
noreset is     : no
hangup is      : no
nolock is      : no
send_cmd is    : sz -vv
receive_cmd is : rz -vv -E
imap is        :
omap is        :
emap is        : crcrlf,delbs,
logfile is     : none
initstring     : none
exit_after is  : not set
exit is        : no

Type [C-a] [C-h] to see available commands
Terminal ready
ati
Manufacturer: Tri Cascade Inc.
Model: SG500M2-X
Revision: RXMG1.20.00.326_0R05
SVN: 02
IMEI: 016371000xxxxxx
+GCAP: +CGSM

OK

44 Odpowiedź przez MiG25

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Ta komenda jest najprawdopodobniej odpwiedzialna z tryb , w jakim jes sprzęt

at+usbcomp?
+USBCOMP? = rndis(9058)

OK

45 Odpowiedź przez MiG25 (edytowany przez MiG25 2025-11-30 22:14:15)

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Sam modem wsadziłem do mojej nieużywanej obudowy  Dual-Q 5G2PHY https://eko.one.pl/forum/viewtopic.php? … 82#p313882

No i w porównaniu z orginalnymi antenami ,gdzie było DL 210Mbps i 15Mbps UL
https://www.speedtest.net/result/18540282143.png

Widać patyki podwoiły UL....
Wg web modem agreguje tylko B1+n78 (karta VM)
Sama obudowa bez problemu działa jako przejściówka m.2 - USB3.0 ( no ale to raczej nic dziwnego) , gniazdo LAN wiadomo , nie działa smile

46 Odpowiedź przez MiG25

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

Lista teoretycznie wszystkich komend (choć nie zawsze to wszystkie)

at+clac
&C
&D
&E
&F
&S
&V
&W
E
I
L
M
Q
V
X
Z
T
P
\Q
\S
\V
%V
D
A
H
O
S0
S2
S3
S4
S5
S6
S7
S8
S9
S10
S11
S30
S103
S104
+FCLASS
+ICF
+IFC
+IPR
+GMI
+GMM
+GMR
+GCAP
+GSN
+DR
+DS
+CMEE
+WS46
+PACSP
+CLCC
+CBST
+CRLP
+CV120
+CHSN
+CSSN
+CREG
+CGREG
+CEREG
+C5GREG
+CSCS
+CSTA
+CR
+CEER
+CRC
+CGDCONT
+CGDSCONT
+CGTFT
+CGEQREQ
+CGEQMIN
+CGEQOS
+CGCONTRDP
+CGSCONTRDP
+CGTFTRDP
+CGEQOSRDP
+CGQREQ
+CGQMIN
+CGEREP
+CGPADDR
+CGDATA
+CGCLASS
+CGPIAF
+C5GNSSAI
+C5GNSSAIRDP
+CGSMS
+CSMS
+CMGF
+CSAS
+CRES
+CSCA
+CSMP
+CSDH
+CSCB
+C5GSMS
+C5GUSMS
+ES
+ESA
+CMOD
+CEMODE
+CVHU
+QCGEQMIN
+QCGEQOS
+QCGEQREQ
+QCGQMIN
+QCGQREQ
+QCGTFT
+CEMBMSCFG
+CEMBMSSRV
+CEMBMSDATA
+CEMBMSCNT
+CEMBMSSAI
+CSQ
+CBC
+CPAS
+CPIN
+CMEC
+CIND
+CMER
+CGATT
+CGACT
+CGCMOD
+CPBS
+CPBR
+CPBF
+CPBW
+CPMS
+CNMI
+CMGL
+CMGR
+CMGS
+CMSS
+CMGW
+CMGD
+CMGC
+CNMA
+CMMS
+CHUP
+CCFC
+CCUG
+COPS
+CLCK
+CPWD
+CUSD
+CAOC
+CACM
+CAMM
+CPUC
+CCWA
+CHLD
+CIMI
+CGMI
+CGMM
+CGMR
+CGSN
+CNUM
+CSIM
+CRSM
+CCLK
+COPN
+CPOL
+CPLS
+CTZR
+CTZU
+CLAC
+CLIP
+COLP
+CDIP
+CTFR
+CLIR
+VTS
+ICCID
+CUAD
+CEAP
+CERP
+CSTF
+CSDF
+CVMOD
+CEN
+CNMPSD
+CMCCS
+CCMMD
+CCFCU
+CSUPI
+CPINR
+CESQ
+LCAINFO
+QCVER
+CEISN
+CESQDBM
+CEIGETEID
+CEITHERM
+CEIFACRESET
+CEISSID
+PRODUCTINFO
+5GDISP
+ANTSWITCH
+FWNV
+BINFO
+CEISWITCHSIM
+CEISAR
+CEIGPIO
+BGPS
+BSVINFO
+BNMEA
+BNRINFO
+BGPSPRM
+BCONFIG
+BATLOG
+NRCAINFO
+CFUN
$QCPWRDN
+CFOTA
+USBCOMP
$QCSIMSTAT
$QCPBMPREF
$CREG
$CCLK
$QCCNMI
*CNTI
$QCCLR
$QCDMR
$QCDNSP
$QCDNSS
$QCTER
$QCSIMAPP
$QCPINSTAT
$QCPDPP
$QCPDPLT
$QCDGEN
$QCPDPCFGE
$QCANTE
$QCRPW
$QCSQ
$CSQ
$QCSYSMODE
$QCCTM
$QCBANDPREF
^PREFMODE
^SYSINFO
^SYSCONFIG
^CARDMODE
^DSCI
$QCVOLT
$QCHWREV
$QCBOOTVER
$QCDEFPROF
$QCMRUE
$QCMRUC
$QCAPNE
$QCPDPIMSCFGE
$QCCLAC
^SPN
$QCRMCALL
$QCDRX
$QCRSRP
$QCRSRQ
$QCACQDBC
$QCATMOD
$QCCOPS
^MODE
$QCSIMT
$QCNSP
$QCRCIND
$QCCSGCOPS
$QCPDPCFGEXT
$QCPRFCRT
$QCPRFMOD
$QCRSCP
$QCECNO
$QCPCOLIST
$QCMSISDN
$QCPCOMSISDN
$QCCALLATTR
$QCIMSSRV
$QCCCFC
$CEINSP

Może ma ktoś jakąś listę (może producenta Compal , a może Tri Cascade) , co by zobaczyć coś więcej...

47 Odpowiedź przez MiG25 (edytowany przez MiG25 2025-12-01 11:47:18)

  • MiG25
  • Użytkownik
  • Nieaktywny
  • Zarejestrowany: 2014-07-23
  • Posty: 3,782

Odp: Stick 5G/LTE na SDX55

at+nrcainfo
+NRCAINFO:
CA enable:0
PCC   Band:78 RSRP:-88 dbm EARFCN:639072 PCI:100
SCC 1 Band:<NA> RSRP:<NA> dbm
SCC 2 Band:<NA> RSRP:<NA> dbm
SCC 3 Band:<NA> RSRP:<NA> dbm
SCC 4 Band:<NA> RSRP:<NA> dbm
SCC 5 Band:<NA> RSRP:<NA> dbm
SCC 6 Band:<NA> RSRP:<NA> dbm
SCC 7 Band:<NA> RSRP:<NA> dbm


OK
at+lcainfo
+LCAINFO:
CA enable:0
PCC   Band:3 RSRP:-88 dbm
SCC 1 Band:<NA> RSRP:<NA> dbm
SCC 2 Band:<NA> RSRP:<NA> dbm
SCC 3 Band:<NA> RSRP:<NA> dbm
SCC 4 Band:<NA> RSRP:<NA> dbm
SCC 5 Band:<NA> RSRP:<NA> dbm
SCC 6 Band:<NA> RSRP:<NA> dbm
SCC 7 Band:<NA> RSRP:<NA> dbm


OK

A jak jest agregacja to tak:
at+lcainfo
+LCAINFO:
CA enable:1
PCC   Band:3 RSRP:-88 dbm
SCC 1 Band:7 RSRP:-109 dbm
SCC 2 Band:1 RSRP:-92 dbm
SCC 3 Band:<NA> RSRP:<NA> dbm
SCC 4 Band:<NA> RSRP:<NA> dbm
SCC 5 Band:<NA> RSRP:<NA> dbm
SCC 6 Band:<NA> RSRP:<NA> dbm
SCC 7 Band:<NA> RSRP:<NA> dbm


OK

Do sygnału jeszcze takie coś jest , tyle ,że odpowiedź długo trwa ( jakieś 3s) ,ale za to mówi jakie mimo ,itp smile :

OK
at+bnrinfo
NR BAND:78, EARFCN:639072 DL_bandwidth:100MHz
physical cell ID:100, averaged PUSCH TX power :12 dBm, averaged PUCCH TX power :23 dBm,
RX Power Info:
NR5G: RSRQ -13 dB, RSRP -104 dBm,SINR 18 dB
RX0 power: -89 dBm,ecio: -10 dB, rsrp: -99 dBm, phase: 0 degree, sinr: 12 dB
RX1 power: -92 dBm,ecio: -11 dB, rsrp: -102 dBm, phase: 0 degree, sinr: 8 dB
RX2 power: -95 dBm,ecio: -11 dB, rsrp: -106 dBm, phase: 0 degree, sinr: 8 dB
RX3 power: -87 dBm,ecio: -10 dB, rsrp: -98 dBm,phase: 0 degree,sinr: 18 dB
NR CQI 11,RANK 1
Serving Beam SSB index 4,FR2 serving Beam:255,255
NR5G RRC STATE:UNKNOWN


OK
at+binfo
<LTE PCC INFO>:EARFCN 1474,TAC 1510
Serving Cell ID 1277010,physical cell ID 100
BAND 3,dl_bandwidth 4,ul_bandwidth 4
RX Power Info:
RSRQ -11 dB, RSRP -87 dBm,SINR 14 dB
RX0 power: -59 dBm
RX0 ecio: -8 dB
RX0 rsrp: -86 dBm
RX0 phase: 0 degree
RX0 sinr: 14 dB
RX0 cinr: 10 dB
RX1 power: 0 dBm
RX1 ecio: -3 dB
RX1 rsrp: -256 dBm
RX1 phase: 0 degree
RX1 sinr: 8 dB
RX1 cinr: 8 dB
RX2 power: 0 dBm
RX2 ecio: -3 dB
RX2 rsrp: -256 dBm
RX2 phase: 0 degree
RX2 sinr: 8 dB
RX2 cinr: 255 dB
RX3 power: 0 dBm
RX3 ecio: -3 dB
RX3 rsrp: -256 dBm
RX3 phase: 0 degree
RX3 sinr: 7 dB
RX3 cinr: 255 dB
TX POWER INFO:
tx_pwr: -19 dBm,pa_gain_state 0
prach -1,srs -32768,pucch -190,pusch50
LTE Modulation:
uplink modulation num_layer  1 num_mimo_layers 0 num_config_layers 0
uplink modulation layer 0  64QAM
uplink modulation layer 1  BPSK
downlink modulation num_layer  1 num_mimo_layers 1 num_config_layers 2
downlink modulation layer 0  QPSK
downlink modulation layer 1  BPSK
PCC CQI 12 9
LTE RRC STATE:CONNECTED

48 Odpowiedź przez spinoff (edytowany przez spinoff 2026-03-03 21:00:34)

  • Zarejestrowany: 2022-10-16
  • Posty: 48

Odp: Stick 5G/LTE na SDX55

Jako szczęśliwy (na razie) posiadacz ww. urządzenia odtworzyłem powyższe kroki i... muszę przyznać... działa.
Switch_Tool ruszył mi na Win11 bez konieczności doinstalowywania  Visual-C-Runtimes w wersji na x86 i  VC_redist.x86.ex reszta jak wyżej.

https://zapodaj.net/images/f3d5a275421a2.png

T:  Bus=03 Lev=02 Prnt=02 Port=00 Cnt=01 Dev#=  4 Spd=5000 MxCh= 0
D:  Ver= 3.20 Cls=00(>ifc ) Sub=00 Prot=00 MxPS= 9 #Cfgs=  1
P:  Vendor=04b7 ProdID=9058 Rev= 4.14
S:  Manufacturer=Tri Cascade Inc.
S:  Product=VOS_5G
S:  SerialNumber=d6519ff3
C:* #Ifs= 5 Cfg#= 1 Atr=a0 MxPwr=896mA
A:  FirstIf#= 0 IfCount= 2 Cls=ef(misc ) Sub=04 Prot=01
I:* If#= 0 Alt= 0 #EPs= 1 Cls=ef(misc ) Sub=04 Prot=01 Driver=rndis_host
E:  Ad=81(I) Atr=03(Int.) MxPS=   8 Ivl=32ms
I:* If#= 1 Alt= 0 #EPs= 2 Cls=0a(data ) Sub=00 Prot=00 Driver=rndis_host
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
I:* If#= 2 Alt= 0 #EPs= 2 Cls=ff(vend.) Sub=ff Prot=30 Driver=option
E:  Ad=82(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=01(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
I:* If#= 3 Alt= 0 #EPs= 2 Cls=ff(vend.) Sub=42 Prot=01 Driver=usbfs
E:  Ad=02(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=83(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
I:* If#= 4 Alt= 0 #EPs= 3 Cls=ff(vend.) Sub=00 Prot=00 Driver=option
E:  Ad=85(I) Atr=03(Int.) MxPS=  10 Ivl=32ms
E:  Ad=84(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=03(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms

No i po przełączeniu na OpenWRT trzeba najpierw zainstalować adb , oraz zainicjować sterownik do adb komendą "adb devices"  Po czym możemy ręcznie dodać option : echo "04b7 9058" > /sys/bus/usb-serial/drivers/option1/new_id

Bez wcześniejszego wykrycia adb , porty szeregowe przejełby również ten od adb , i modem w momencie by się zawiesił...
No i teraz już na porcie ttyUSB1 są komendy AT

Mam pytanie czy można to jakoś zautomatyzować przy starcie w tej lub innej formie? tak żeby  ttyUSB1 było rozpoznane przez Openwrt od razu po uruchomieniu (wpięciu) urządzenia (udev...?).

49 Odpowiedź przez Cezary

  • Skąd: Warszawa
  • Zarejestrowany: 2006-02-25
  • Posty: 115,877

Odp: Stick 5G/LTE na SDX55

W /etc/rc.local dodaj.

Masz niepotrzebny router, uszkodzony czy nie - chętnie przygarnę go.

Cezary's Strona

50 Odpowiedź przez spinoff (edytowany przez spinoff 2026-02-21 21:51:03)

  • Zarejestrowany: 2022-10-16
  • Posty: 48

Odp: Stick 5G/LTE na SDX55

próbowałem...

# Put your custom commands here that should be executed once
# the system init finished. By default this file does nothing.

adb devices
echo "04b7 9058" > /sys/bus/usb-serial/drivers/option1/new_id

exit 0


nie poszło... po starcie dostaję:

I:* If#= 0 Alt= 0 #EPs= 1 Cls=ef(misc ) Sub=04 Prot=01 Driver=rndis_host
E:  Ad=81(I) Atr=03(Int.) MxPS=   8 Ivl=32ms
I:* If#= 1 Alt= 0 #EPs= 2 Cls=0a(data ) Sub=00 Prot=00 Driver=rndis_host
E:  Ad=8e(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=0f(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
I:* If#= 2 Alt= 0 #EPs= 2 Cls=ff(vend.) Sub=ff Prot=30 Driver=option
E:  Ad=82(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=01(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
I:* If#= 3 Alt= 0 #EPs= 2 Cls=ff(vend.) Sub=42 Prot=01 Driver=option
E:  Ad=02(O) Atr=02(Bulk) MxPS=1024 Ivl=0ms
E:  Ad=83(I) Atr=02(Bulk) MxPS=1024 Ivl=0ms
I:* If#= 4 Alt= 0 #EPs= 3 Cls=ff(vend.) Sub=00 Prot=00 Driver=option


w logu jest coś takiego

[21 lut 2026, 21:47:35 CET] daemon.info: procd: - init complete -
[21 lut 2026, 21:47:38 CET] user.notice: adb-enablemodem: ERROR: unknown device /bin/sh: uci: no:/bin/sh: uci: no

nie mam tego pakietu (adb-enablemodem) a jak próbuję go dodać to się wszystko wiesza
LuCI openwrt-25.12 branch (26.051.08954~f11a0bf) / OpenWrt 25.12.0-rc5 (r32673-482ba7230a)
